Yun Blue Square node
Yun Blue Square node
Regular price
€2,90 EUR
Regular price
Sale price
€2,90 EUR
Unit price
per
Tax included.
Couldn't load pickup availability
What you will get:
The Hardware Design Template package for the easiest schematic design and PCB layout of an Industrial node, IoT node or similar device.
The Hardware Design Template package contains:
- Design data of the verified PCB template.
- A design library of all used symbols.
- A design library of all used footprints.
- Clean and easy to order BOM of all components compatible with the enclosure openings.
- Instructions on how to order the enclosure by yourself.
The Hardware Design Template supports:
- PoE RJ45 jack
- micro USB receptacle
- USB-A receptacle
- microSD card slot
The used enclosure is Hammond Manufacturing 1593HAMARTBU.
What you will not get:
- Any physical enclosure or any piece of material.
Disclaimer
💾 The Hardware Design Template is a downloadable digital product (delivery policy)
Dimensions
Dimensions
74x76x27 mm
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/585D240D-9954-4943-91C8-258CC1E1230E_1_201_a_69c73c16-79bd-4f13-ba96-4d7ced8b6ae4.heic?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/IOT0003_2.png?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/2747DDFF-A70A-44C3-8465-DD1EF209EB5D_1_201_a.heic?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/IOT0003_1.png?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/IOT0003_3.png?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/IOT0003_4.png?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/IOT0003_5.png?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/IOT0003_6.png?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/IOT0003_7.png?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/IOT0003_8.png?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/IOT0003_9.png?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/IOT0003_10.png?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/37EAE1EA-ABB3-4E50-AF40-8A7CACE5AC51_1_201_a_cefbb0d7-f9a4-4d5a-abf1-b59e8f2ddf67.heic?v=1663491343&width=1445)
![Yun Blue Square node](http://beny-devices.eu/cdn/shop/products/3C199032-BB21-4EDD-B290-C86043BA3495_1_201_a_42b24f65-c243-4768-9450-2a1d39b3b358.heic?v=1663491343&width=1445)
![](http://beny-devices.eu/cdn/shop/products/968FAB21-0522-4DB5-9FFF-EF91B6C02992_1_201_a.heic?v=1663490048&width=1500)
A jump start
Mechanical simplicity along with tested components keep you on track to the final product.
-
ECAD project
Simple and clean ECAD project. The size of the PCB is the maximum possible and the shape always follows the enclosure borders.
-
Bill of material
List of all recommended components that were verified to be perfectly fiting the enclosure openings.
