BLE sensor 1551V11

BLE sensor 1551V11

€14,90 EUR
€14,90 EUR
Sale Sold out
Tax included.
Size

What you will get:

The complete Hardware Design Template package for the BLE sensor device.

The Hardware Design Template package contains the following:

  • Design data of the verified BLE sensor device.
  • Complete ECAD project
  • Independent footprint and symbol libraries
  • Complete BOM
  • Complete manufacturing data for both PCB and Assembly
  • Interactive BOM file
  • Instructions on how to order the enclosure
  • 3D STEP mode of the entire device

The used enclosure is Hammond Manufacturing 1551V11. More information about the design and manufacturing in the Using templates article.

What you will not get:

  • Any physical enclosure or any piece of material.

Disclaimer

💾 The Hardware Design Template is a downloadable digital product (delivery policy)

Dimensions

∅ 45 mm

View full details

A jump start

Mechanical simplicity along with tested components keep you on track to the final product.

  • ECAD project

    Simple and clean ECAD project. The size of the PCB is the maximum possible and the shape always follows the enclosure borders.

  • Bill of material

    List of all recommended components that were verified to be perfectly fiting the enclosure openings.
